ABB 3BHB003154R0101/3BHL000389P0104 Excitation System or Inverter Trigger Board

In stock

This excitation system or inverter trigger board from ABB is designed to deliver superior performance and reliability in industrial control applications. It plays a critical role in controlling the operation of electrical machines by managing the current supplied to the field windings. Suitable for use in power generation plants, electric drives, and renewable energy systems.

Manufacturer:ABB

Model:3BHB003154R0101, 3BHL000389P0104

Application:Excitation System, Inverter

Frequency Range:Up to 599 Hz

Protection Rating:IP66

Control Method:Sensorless Vector Control

Safety Feature:Safe Torque Off Function (SIL3)

The ABB 3BHB003154R0101 and 3BHL000389P0104 trigger boards are meticulously engineered for demanding industrial applications including textile, printing, rubber and plastics, and woodworking. These boards feature exceptionally compact designs and a uniform design philosophy, which facilitate quick and easy installation and maintenance.

Key features include application macros and panel assistants that simplify commissioning processes, making setup faster and more efficient. Additionally, the Safe Torque Off function ensures operational safety, meeting stringent safety standards (SIL3).

Equipped with sensorless vector control, these boards support both induction motors and permanent magnet motors up to 599 Hz, providing exceptional performance and reliability under varying conditions.

An integrated braking chopper is included in the design, contributing to energy efficiency and extended system lifespan. All circuit boards are coated for protection against environmental factors, ensuring durability in harsh conditions.

Available in product variants suited for various applications, including a variant specifically designed for solar pump drives, this trigger board is a versatile solution for modern industrial automation needs.
