ABB AX561 A1 S500 Analog Input/Output Module – Advanced Industrial Control Solutions

Input/Output Channels:16

Analog Input Range:4-20mA

Analog Output Range:0-20mA

Power Supply:DC 24V

Communication Interface:PROFIBUS DP

Operating Temperature:-25°C to +60°C

Storage Temperature:-40°C to +70°C

Dimensions (mm):122x109x50

Weight (kg):0.4

    Integrating advanced technology, the ABB AX561 A1 S500 Analog IO Module ensures accurate and stable data transmission, making it an indispensable component for industrial control systems.

    Featuring an extended temperature range (-25°C to +60°C), this module is built to withstand harsh industrial environments, ensuring reliable operation under various conditions.

    With its compact design (112mm x 51mm x 33mm) and lightweight structure (approx. 150g), the AX561 A1 S500 is easily installed and integrated into existing systems without compromising on space or efficiency.

    Equipped with a Profinet communication interface, it seamlessly connects to a wide array of automation devices, enhancing system interoperability and reducing integration costs.

    This module supports a broad input range from -10V to +10V and outputs signals in 4-20mA format, making it compatible with a variety of sensors and actuators. Its high load capacity (up to 750 Ohm) ensures efficient signal handling even under demanding conditions.
