ABB PDB-02 3HNA023093-001: Thermocouple/mV Input Module for Industrial Automation

In stock

The ABB PDB-02 Thermocouple/mV Input Module, model 3HNA023093-001, is a highly precise temperature and voltage measurement solution designed for industrial automation systems. It seamlessly integrates with PLCs and offers exceptional accuracy and reliability.

Thermocouple Compatibility:Wide range of thermocouple types supported

Voltage Range:0-10V or 4-20mA input range

Resolution:0.01°C or 0.01mV

Sampling Rate:10 samples per second

Power Consumption:Max. 15mA

Environmental Conditions:Operating Temp: -20°C to +55°C, Storage Temp: -40°C to +70°C

Connection Type:Standard 2-wire connection

The ABB PDB-02 3HNA023093-001 Thermocouple/mV Input Module is an essential component for any industrial control system requiring accurate temperature monitoring. Its compatibility with various thermocouple types ensures seamless integration into diverse systems.

With an exceptionally wide input range from -200°C to +1800°C, this module is capable of handling a vast array of industrial processes, making it suitable for both high and low temperature applications.

The direct conversion of thermocouple outputs to millivolt signals facilitates easy integration into existing digital systems, streamlining data processing and enhancing system efficiency.

Featuring an accuracy of ±0.5% of full scale, the ABB PDB-02 3HNA023093-001 guarantees reliable and precise temperature measurements, crucial for maintaining process control and safety standards.

Low power consumption at less than 2.5mA at 24V DC ensures efficient operation and reduces energy costs, contributing to a more sustainable and cost-effective industrial setup.

ABB PDB-02 3HNA023093-001 Thermocouple/mV Input Module
