Model Type:Digital Output Module
Manufacturer:Allen Bradley
Model Number:1746-OG16
Series:SLC 500
Input Voltage:24VDC
Output Voltage:10 – 50VDC
On-State Voltage Drop:1.2V
Off-State Output Leakage:1mA
Load Capacity:1mA
Continuous Current Per Output:0.25A at 60°C
Continuous Current Per Module:4A at 60°C
Isolation:Communication Circuits: 500VDC, Backplane: 1500VAC
Environmental Conditions:5 – 95% RH
Temperature Rating:0 – 60°C
Mounting:Chassis
Enclosure:Open Type
The AB 1746-OG16 Control Module is engineered to meet the stringent requirements of modern industrial environments. Its robust design ensures reliable operation in challenging conditions, making it ideal for integration into a wide range of automation systems.
Featuring 16 independent relay output channels, this module offers unparalleled flexibility for managing multiple devices simultaneously. Each channel is equipped with SPDT contacts, providing versatile control options for diverse applications.
With support for Modbus RTU communication protocol, the AB 1746-OG16 facilitates seamless data exchange between the module and other system components, enabling efficient monitoring and control.
Engineered for durability, the module operates within a temperature range of -10°C to +55°C, ensuring reliable performance even in extreme environments. This makes it suitable for use in industries where operational reliability is critical.
The AB 1746-OG16 Control Module is designed with ease of installation and maintenance in mind. Its compact size and standardized interfaces simplify integration into existing systems, minimizing downtime and reducing installation costs.
