Resolution:3600 Pulses/Rev
Accuracy:+/- 1.5 Count
Operating Temperature:-20°C to +70°C
Output Type:Open Collector
Operating Voltage:DC 12V to 35V
Load Resistance:Max. 50Ω
Enclosure Type:IP67 Rated
Connection Type:M12 Connector
The OMRON E6H-CWZ3X Industrial Encoder, 3600PULSE is engineered to deliver exceptional performance in harsh industrial environments. This encoder boasts a high resolution of 3600 pulses per revolution, ensuring precise measurement of rotational positions. Its wide operating voltage range of 12V to 36V DC makes it suitable for various power sources in different industrial setups.
Withstanding temperatures from -25°C to +85°C, this encoder ensures reliable operation under extreme conditions. It can withstand speeds up to 1,000 revolutions per minute, making it ideal for high-speed applications in manufacturing, robotics, and other automation sectors.
Featuring an open collector output, the E6H-CWZ3X supports versatile integration with control systems. Its digital communication interface facilitates easy connection to automation equipment, enhancing system efficiency and reducing installation complexity.
The 4-bit binary count signal output provides a clear and robust feedback mechanism, improving the accuracy of positioning and motion control. This encoder’s flange mount design offers flexibility in installation, accommodating diverse mechanical configurations.
Engineered with precision and durability in mind, the OMRON E6H-CWZ3X Industrial Encoder, 3600PULSE is a critical component for enhancing the performance of industrial automation systems. Its combination of high resolution, wide operating parameters, and robust construction ensures reliable operation in demanding industrial environments.
