Output Frequency Range:1 Hz to 8 GHz
Signal Types:Arbitrary, Pulse, Sine, Square, Triangle
Amplitude Range:0.5 μV to 1 Vpp
Output Power:Max. 5 W
Accuracy:± 0.01% + 1 LSB
Output Impedance:50 Ω, 100 Ω, 500 Ω, 2000 Ω
Rack Size:1U
Power Supply:AC 90-264 V, 47-63 Hz
Introducing the Tektronix VX4802, a high-performance signal generator specifically tailored for demanding RF and microwave applications. This precision instrument delivers unparalleled accuracy and reliability, making it an indispensable tool in the hands of engineers and researchers worldwide.
With a maximum output power of 30 dBm, the VX4802 is capable of handling a wide range of test and measurement tasks, from basic signal generation to complex modulation analysis. Its extensive frequency range from 1 MHz to 4 GHz ensures compatibility with various standards and protocols.
Equipped with advanced signal shaping technology, the VX4802 offers exceptional resolution bandwidth from 1 Hz to 1 MHz, ensuring precise control over your signals. Its low output distortion of less than 0.05 dBc at 1 MHz and 1 kHz makes it ideal for high-fidelity signal testing.
The phase noise performance of the VX4802 is superior, with values better than -120 dBc at a 10 kHz offset. This feature is critical for maintaining signal integrity in sensitive communication systems, enabling clear and reliable data transmission.
The VX4802 boasts remarkable repeatability, with an accuracy of ±0.001 Hz across its entire frequency range. This consistency ensures that your measurements are not only precise but also repeatable, providing confidence in your experimental results.
