TRICONEX DO3401 Digital Output Module

Model:DO3401

Brand:TRICONEX

Nominal Output Voltage:24 VDC

Operational Voltage Range:15 to 30 VDC

Absolute Maximum Output Voltage:33 VDC

Absolute Maximum Reverse Input Voltage:-0.6 VDC

Output Current:<4.8 A, self-limiting 3.0 A, typical

Degraded Mode Output Current:>0.7 A, self-limiting 1.5 A, typical

Field Alarms:Loss of field power, output point shorted

Loop-back Thresholds:0–5 VDC = Off region, 6–14 VDC = Transition region, 15–30 VDC = On region

Leakage to Load:(Off)

    The TRICONEX DO3401 Digital Output Module is engineered for demanding industrial environments. Designed to handle critical processes, this module offers robust performance with its nominal output voltage of 24 VDC and an operational voltage range from 15 to 30 VDC. Its absolute maximum output voltage of 33 VDC ensures it can manage peak loads without compromising reliability.

    The DO3401 supports output currents up to 4.8 A, self-limiting, which is ideal for various control applications. In degraded mode, it maintains a safe output of 1.5 A, typical, safeguarding the system from overloading.

    Built with durability in mind, the module is equipped to detect field alarms such as loss of field power or an output point shorted, ensuring seamless operation even under unexpected conditions. With its straightforward installation and maintenance, the TRICONEX DO3401 module stands out as a premium choice for industrial automation systems.
